Next generation monolithic membrane

Why Partel EXOPERM MONO 150 Connex?

Integrated tapes that facilitate easier, permanent connections
Developed based on Monolithic Technology
Highly breathable membrane with a low Sd value 0.07 m
Class W1 resistance to water penetration
Optimal UV and temperature resistance
Resistant to driving rain and wind
Windtight, but diffusion open
Airtight System, featuring an air permeance value of <0.001m3/(m2h)
Excellent aging resistance due to the Monolithic Technology
Helps to prevent structural damage in any types of buildings

Technical Data

WEIGHT	EN 1849-2	150 G/M²
SD-VALUE M	EN ISO 12572-C	0.07 M
WATER RESISTANCE	EN 1928	W1 (BEFORE & AFTER AGEING)
TENSILE STRENGTH MD/CD	EN 12311-1	255 / 145 N / 50mm
NAIL TEAR RESISTANCE MD / CD*	EN 12310-1	130 / 160 N
TEMPERATURE RESISTANCE		-40°C TO 80°C
UV RESISTANCE		3 MONTHS

*MD = longitudinal CD = transversal

Application

EXOPERM MONO 150 Connex is an external breather membrane, with integrated adhesive tapes, designed for use on the cold side of insulation on facade wall and roof applications.

Suitable for:

Facades with closed joints
Timber and steel framed constructions
Warm, cold and hybrid roof applications
Pitched or flat roofs
Sarking boards
All insulation types

Monolithic Technology

EXOPERM MONO 150 Connex is a 3-Ply sarking, roof underlay and wind barrier with next generation monolithic functional layer and integrated adhesive tapes.

The monolithic functional layer provides enhanced protection for the building envelope:

transports vapour to outside
is vapour open whilst having excellent waterproofing properties
creates a complete wind tight, waterproof membrane that actively expels out any water/humidity, unlike most micro-porous membranes that rely on small pores (which have the tendency to block)
